AiDiWatt Lighting is a professional LED Downlights manufacturer and wholesale supplier in China.
There are recessed led downlights (Round/Square, Trimless, Fixed/Tiltable), surface mounted led downlights etc. Use brand LED Chips such as CREE, CITIZEN, OSRAM, etc. Use high-quality led drivers such as Lifud, Eaglerise, Aidimming, BOKE, Euchips, OSRAM, PHILIPS, Tridonic, etc.
We offer customized solutions, OEM, ODM service. Tell us what you want now.
Illuminating your space with top-quality LED downlights! Whether you’re looking to enhance the ambiance of your living room, highlight architectural features in your office, or create a warm and inviting atmosphere in your restaurant, LED downlights are the perfect lighting solution. Designed to provide powerful illumination while consuming less energy, these modern lighting fixtures offer a multitude of benefits for both residential and commercial spaces. In this guide, we will delve into the world of LED downlights, exploring their various types, features, and installation options. We will also discuss the advantages of LED technology over traditional lighting sources, such as incandescent and halogen bulbs. So, get ready to transform your space into a visually stunning masterpiece with the help of top-quality LED downlights. Let’s dive in and discover the endless possibilities that await!
Multiple LED Downlights for your Choice
LED downlights come in various types, each offering unique features and functionalities. The most common types include fixed downlights, adjustable downlights, and gimbal downlights.
Fixed downlights are the standard choice for most applications. They provide a fixed beam angle and are ideal for general lighting purposes. Fixed downlights are commonly used in hallways, kitchens, and commercial spaces where a uniform lighting distribution is desired.
Adjustable downlights, on the other hand, allow you to change the beam angle to suit your specific lighting requirements. These downlights are perfect for accent lighting, as they can be directed towards specific objects or areas that you want to highlight. Adjustable downlights are commonly used in art galleries, retail stores, and display areas.
Gimbal downlights offer the most flexibility, as they allow both rotation and tilting of the light source. This type of downlight is ideal for spaces where the lighting needs to be adjusted frequently, such as in galleries or exhibitions. Gimbal downlights provide the ability to direct the light precisely to achieve the desired effect.
Cabinet Series LED Downlights
Watt: 3W / 5W
Working voltage: AC200-240V 50/60Hz
Light source: OSRAM LED/ CREE COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 15°, 24°, 38°, 50°
Lamp Head: Fixed, Tiltable for optional
Driver: Lifud / Eaglerise ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White, Matt Black for optional (Other colour on request)
IP rating: IP44 grade
| Watt | 3W | 3W | 5W |
|---|---|---|---|
| Lumen | 150lm | 280lm | 450lm |
| Dimension | Φ31*H26.8mm | Φ46*H30mm | Φ46*H50mm |
| Cut out | Φ25mm | Φ40mm | Φ40mm |
Nona Series LED Downlights
Watt: 5W, 7W, 10W, 12W, 15W, 20W, 30W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 15°, 24°, 38°, 60°
Lamp Head: Fixed, Tiltable, Round, Square, Trimless for optional
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White, Matt Black for optional (Other colour on request)
IP rating: IP44 grade
| Watt | 5W | 7W | 10W | 12W | 15W | 20W | 30W |
|---|---|---|---|---|---|---|---|
| Lumen | 350lm | 560lm | 800lm | 960lm | 1200lm | 1600lm | 2400lm |
| Cut out | Φ55mm | Φ75mm | Φ75mm | Φ75mm | Φ75mm | Φ95mm | Φ125mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Mamba Series LED Downlights
Watt: 10W, 12W, 15W, 20W, 25W, 30W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 15°, 24°, 38°
Lamp Head: Tiltable, Round
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White, Matt Black for optional (Other colour on request)
IP rating: IP44 grade
| Watt | 10W | 12W | 15W | 20W | 25W | 30W |
|---|---|---|---|---|---|---|
| Lumen | 800lm | 960lm | 1200lm | 1600lm | 2000lm | 2400lm |
| Cut out | Φ75mm | Φ75mm | Φ95mm | Φ95mm | Φ125mm | Φ125mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Jaga Series LED Downlights
Watt: 10W, 15W, 20W, 30W, 35W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 12°, 24°, 38°, 55°
Lamp Head: Fixed, Round
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White, Matt Black for optional (Other colour on request)
IP rating: IP44 grade
| Watt | 10W | 15W | 20W | 30W | 35W |
|---|---|---|---|---|---|
| Lumen | 800lm | 1200lm | 1600lm | 2400lm | 2800lm |
| Cut out | Φ75mm | Φ90mm | Φ125mm | Φ125mm | Φ140mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Paris Series LED Downlights
Watt: 10W, 2*10W, 3*10W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 15°, 24°, 36°, 55°
Lamp Head: Fixed, Round/Square
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White, Matt Black for optional (Other colour on request)
IP rating: IP44 grade
| Watt | 10W | 10W | 2*10W | 3*10W |
|---|---|---|---|---|
| Lumen | 800lm | 800lm | 2*800lm | 3*800lm |
| Cut out | Φ75mm | L75*W75mm | L150*W75mm | L230*W75mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Godan Series LED Downlights
Watt: 10W, 20W, 30W, 40W, 50W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 60°
Lamp Head: Fixed, Round/Square
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White, Matt Black for optional (Other colour on request)
IP rating: IP44 grade
| Watt | 10W | 20W | 30W | 40W | 50W |
|---|---|---|---|---|---|
| Lumen | 800lm | 1600lm | 2400lm | 3200lm | 4000lm |
| Cut out | Φ100mm | Φ125mm | Φ145mm | Φ180mm | Φ215mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Watino Series LED Downlights
IP65 Waterproof
Watt: 15W, 20W, 30W, 40W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 15°, 24°, 38°, 60°
Lamp Head: Fixed, Round/Square
Driver: BOKE waterproof driver ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White (Other colour on request)
IP rating: IP65 grade
| Watt | 15W | 20W | 30W | 40W |
|---|---|---|---|---|
| Lumen | 1200lm | 1600lm | 2400lm | 3200lm |
| Cut out | Φ90mm | Φ125mm | Φ145mm | Φ165mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Miso Series LED Downlights
Watt: 5W, 10W, 15W, 20W, 25W, 30W, 40W, 50W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 24°, 40°, 60°
Lamp Head: Tiltable, Round
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White (Other colour on request)
IP rating: IP44 grade
| Watt | 5W | 10W | 15W | 20W |
|---|---|---|---|---|
| Lumen | 400lm | 800lm | 1200lm | 1500lm |
| Cut out | Φ75mm | Φ75mm | Φ95mm | Φ115mm |
| Watt | 25W | 30W | 40W | 50W |
|---|---|---|---|---|
| Lumen | 2000lm | 2400lm | 3200lm | 4000lm |
| Cut out | Φ115mm | Φ150mm | Φ150mm | Φ160mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Mano Series LED Downlights
Watt: 5W, 7W, 10W, 15W, 20W, 30W, 40W, 50W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 15°, 24°, 36°, 60°
Lamp Head: Fixed, Round
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White (Other colour on request)
IP rating: IP44 grade
| Watt | 5W | 7W | 10W | 15W |
|---|---|---|---|---|
| Lumen | 400lm | 560lm | 800lm | 1200lm |
| Cut out | Φ75mm | Φ75mm | Φ75mm | Φ95mm |
| Watt | 20W | 30W | 40W | 50W |
|---|---|---|---|---|
| Lumen | 1600lm | 2400lm | 3200lm | 4000lm |
| Cut out | Φ130mm | Φ140mm | Φ140mm | Φ160mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Fany Series LED Downlights
Watt: 15W, 20W, 30W, 40W
Working voltage: AC200-240V 50/60Hz
Light source: Samsung SMD
CRI: >80 (>90 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 90°
Lamp Head: Fixed, Round
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White (Other colour on request)
IP rating: IP44 grade
| Watt | 15W | 20W | 30W | 40W |
|---|---|---|---|---|
| Lumen | 1500lm | 2000lm | 3000lm | 4000lm |
| Dimension | Φ110*H53mm | Φ145*H69mm | Φ190*H86mm | Φ230*H99mm |
| Cut out | Φ95mm | Φ130mm | Φ170mm | Φ210mm |
Fano Series LED Downlights
Watt: 15W, 20W, 30W, 40W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB/CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 60°
Lamp Head: Fixed, Round
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White (Other colour on request)
IP rating: IP44 grade
| Watt | 15W | 20W | 30W | 40W |
|---|---|---|---|---|
| Lumen | 1500lm | 2000lm | 3000lm | 4000lm |
| Dimension | Φ110*H53mm | Φ145*H69mm | Φ190*H86mm | Φ230*H99mm |
| Cut out | Φ95mm | Φ130mm | Φ170mm | Φ210mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Pino Series LED Downlights
Watt: 8W, 12W, 25W, 30W
Working voltage: AC200-240V 50/60Hz
Light source: Samsung SMD
CRI: >80 (>90 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 90°
Lamp Head: Fixed, Round
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White (Other colour on request)
IP rating: IP44 grade
| Watt | 15W | 20W | 30W | 40W |
|---|---|---|---|---|
| Lumen | 1500lm | 2000lm | 3000lm | 4000lm |
| Dimension | Φ110*H53mm | Φ145*H69mm | Φ190*H86mm | Φ230*H99mm |
| Cut out | Φ95mm | Φ130mm | Φ170mm | Φ210mm |
Sany Series LED Downlights
Watt: 15W, 20W, 30W
Working voltage: AC200-240V 50/60Hz
Light source: Samsung SMD
CRI: >80 (>90 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 90°
Lamp Head: Fixed, Round
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White (Other colour on request)
IP rating: IP44 grade
| Watt | 15W | 20W | 30W |
|---|---|---|---|
| Lumen | 1500lm | 2000lm | 3000lm |
| Dimension | Φ145*H49mm | Φ180*H57mm | Φ230*H62mm |
| Cut out | Φ130mm | Φ165mm | Φ210mm |
Closo Series LED Downlights
Watt: 10W, 15W, 20W, 30W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 15°, 24°, 38°
Lamp Head: Tiltable, Round
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White (Other colour on request)
IP rating: IP44 grade
| Watt | 10W | 15W | 20W | 30W |
|---|---|---|---|---|
| Lumen | 800lm | 1200lm | 1600lm | 2400lm |
| Dimension | Φ100*H80mm | Φ125*H120mm | Φ125*H120mm | Φ125*H130mm |
| Cut out | Φ75mm | Φ105mm | Φ105mm | Φ105mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Clasa Series LED Downlights
Watt: 10W, 15W, 20W, 30W, 2*10W, 2*15W, 2*20W, 2*30W, 3*10W, 3*15W, 3*20W, 3*30W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 15°, 24°, 38°, 60°
Lamp Head: Tiltable, Round/Square
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White (Other colour on request)
IP rating: IP44 grade
| Watt | 10W | 15W | 20W | 30W |
|---|---|---|---|---|
| Lumen | 800lm | 1200lm | 1600lm | 2400lm |
| Dimension | Φ115*H95mm | Φ115*H105mm | Φ135*H120mm | Φ135*H130mm |
| Cut out | Φ95mm | Φ95mm | Φ120mm | Φ120mm |
| Watt | 2*10W | 2*15W | 2*20W | 2*30W |
|---|---|---|---|---|
| Lumen | 2*800lm | 2*1200lm | 2*1600lm | 2*2400lm |
| Dimension | L210*W115*H95mm | L250*W135*H120mm | L250*W135*H120mm | L250*W135*H130mm |
| Cut out | L190*W95mm | L230*W115mm | L230*W115mm | L230*W115mm |
| Watt | 3*10W | 3*15W | 3*20W | 3*30W |
|---|---|---|---|---|
| Lumen | 3*800lm | 3*1200lm | 3*1600lm | 3*2400lm |
| Dimension | L300*W115*H95mm | L365*W135*H120mm | L365*W135*H120mm | L365*W135*H130mm |
| Cut out | L280*W95mm | L345*W115mm | L345*W115mm | L345*W115mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Stretch Series LED Downlights
Watt: 7W, 10W, 15W, 25W, 35W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 15°, 24°, 36°
Lamp Head: Tiltable, Round/Square, Trimless
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White (Other colour on request)
IP rating: IP44 grade
| Watt | 7W | 15W | 25W |
|---|---|---|---|
| Lumen | 560lm | 1200lm | 2000lm |
| Dimension | L72*H110mm | L100*H120mm | L130*H135mm |
| Cut out | L65mm | L95mm | L120mm |
| Watt | 2*7W | 2*15W | 2*25W |
|---|---|---|---|
| Lumen | 2*560lm | 2*1200lm | 2*2000lm |
| Dimension | L131*L72*H110mm | L185*L100*H120mm | L240*L130*H135mm |
| Cut out | L121*L65mm | L175*L90mm | L230*L120mm |
| Watt | 3*7W | 3*15W | 3*25W |
|---|---|---|---|
| Lumen | 3*560lm | 3*1200lm | 3*2000lm |
| Dimension | L192*L72*H110mm | L270*L100*H120mm | L345*L130*H135mm |
| Cut out | L182*L65mm | L260*L90mm | L335*L120mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Jana Series LED Downlights
Watt: 30W, 2*30W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 15°, 24°, 36°, 60°
Lamp Head: Tiltable, Round/Square
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White (Other colour on request)
IP rating: IP44 grade
| Watt | 30W | 30W | 2*30W |
|---|---|---|---|
| Lumen | 2400lm | 2400lm | 2*2400lm |
| Dimension | Φ160*H126mm | L160*H125mm | L330*W175*H126mm |
| Cut out | Φ150mm | L150mm | L320*W160mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Grille Series LED Downlights
Watt: 7W, 15W, 20W, 30W, 2*7W, 2*15W, 2*20W, 2*30W, 3*7W, 3*15W, 3*20W, 3*30W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 10°, 24°, 38°, 60°
Lamp Head: Tiltable, Square
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White (Other colour on request)
IP rating: IP44 grade
| Watt | 7W | 15W | 20W | 30W |
|---|---|---|---|---|
| Lumen | 560lm | 1200lm | 1600lm | 2400lm |
| Dimension | L115*W115*H124mm | L140*W140*H139mm | L160*W160*H143mm | L180*W180*H143mm |
| Cut out | L100*W100mm | L125*W125mm | L145*W145mm | L165*W165mm |
| Watt | 2*7W | 2*15W | 2*20W | 2*30W |
|---|---|---|---|---|
| Lumen | 2*560lm | 2*1200lm | 2*1600lm | 2*2400lm |
| Dimension | L215*W115*H124mm | L265*W140*H139mm | L290*W160*H143mm | L330*W180*H143mm |
| Cut out | L200*W100mm | L250*W125mm | L290*W145mm | L330*W165mm |
| Watt | 3*7W | 3*15W | 3*20W | 3*30W |
|---|---|---|---|---|
| Lumen | 3*560lm | 3*1200lm | 3*1600lm | 3*2400lm |
| Dimension | L315*W115*H124mm | L390*W140*H139mm | L450*W160*H143mm | L505*W180*H143mm |
| Cut out | L300*W100mm | L375*W125mm | L440*W145mm | L500*W165mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Snow Series LED Downlights
Watt: 20W, 30W, 40W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 15°, 24°, 38°
Lamp Head: Tiltable, Round
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White (Other colour on request)
IP rating: IP44 grade
| Watt | 20W | 30W | 40W |
|---|---|---|---|
| Lumen | 1600lm | 2400lm | 3200lm |
| Dimension | Φ140*H115mm | Φ160*H130mm | Φ190*H160mm |
| Cut out | Φ125mm | Φ145mm | Φ170mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Qino Series LED Downlights
Watt: 40W, 80W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 24°, 38°, 45°, 60°
Lamp Head: Fixed, Round
Driver: Meanwell HLG, PHILIPS ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White (Other colour on request)
IP rating: IP54 grade
| Watt | 40W | 80W |
|---|---|---|
| Lumen | 4000lm | 8000lm |
| Dimension | Φ175*H130mm | Φ225*H169mm |
| Cut out | Φ150mm | Φ200mm |
*Above lumen is estimated with CITIZEN COB.
Salo Series LED Downlights
Watt: 10W, 20W, 30W, 40W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 20°, 45°
Lamp Head: Fixed, Round/Square
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White /Black (Other colour on request)
IP rating: IP44 grade
| Watt | 10W | 20W | 30W | 40W |
|---|---|---|---|---|
| Lumen | 800lm | 1600lm | 2400lm | 3200lm |
| Dimension | L90*H90mm | L110*H120mm | L130*H135mm | L160*H165mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Baso Series LED Downlights
Watt: 10W, 20W, 30W, 40W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 20°, 45°
Lamp Head: Fixed, Round/Square
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White /Black (Other colour on request)
IP rating: IP44 grade
| Watt | 10W | 20W | 30W | 40W |
|---|---|---|---|---|
| Lumen | 800lm | 1600lm | 2400lm | 3200lm |
| Dimension | L90*H90mm | L110*H120mm | L130*H135mm | L160*H165mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Eiffel Series LED Downlights
Watt: 5W, 10W, 15W, 20W, 2*5W, 2*10W, 2*15W, 2*20W,
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 15°, 24°, 36°, 55°
Lamp Head: Fixed, Square
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White /Black (Other colour on request)
IP rating: IP44 grade
| Watt | 5W | 10W | 15W | 20W |
|---|---|---|---|---|
| Lumen | 400lm | 800lm | 1200lm | 1600lm |
| Dimension | L75*L75*H79mm | L100*L100*H93mm | L100*L100*H93mm | L120*L120*H112mm |
| Watt | 2*5W | 2*10W | 2*15W | 2*20W |
|---|---|---|---|---|
| Lumen | 2*400lm | 2*800lm | 2*1200lm | 2*1600lm |
| Dimension | L75*L150*H79mm | L100*L200*H93mm | L100*L200*H93mm | L120*L240*H112mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Waso Series LED Downlights
Watt: 10W, 15W, 20W, 30W, 40W, 50W, 60W
Working voltage: AC200-240V 50/60Hz
Light source: CREE COB / CITIZEN COB
CRI: >90 (>80 on request)
CCT: 2700K/3000K/4000K/5000K/6500K
Beam angle: 20°, 40°
Lamp Head: Fixed, Round
Driver: Lifud / Eaglerise / OSRAM ( other brand on request)
Driver can be ON.OFF, Triac dimming, 0/1-10V or Dali dimming
Material: Die-casting aluminum
Finish: Matt White /Black (Other colour on request)
IP rating: IP44 grade
| Watt | 10W | 15W | 15W | 20W |
|---|---|---|---|---|
| Lumen | 800lm | 1200lm | 1200lm | 1600lm |
| Dimension | Φ75*H100mm | Φ75*H152mm | Φ95*H100mm | Φ95*H152mm |
| Watt | 30W | 40W | 50W | 60W |
|---|---|---|---|---|
| Lumen | 2400lm | 3200lm | 4000lm | 4800lm |
| Dimension | Φ115*H152mm | Φ140*H162mm | Φ170*H182mm | Φ205*H212mm |
*Above lumen is estimated with CREE COB, if need higher lumen, can choose CITIZEN COB.
Benefits of Using LED Downlights
LED downlights have revolutionized the lighting industry with their numerous advantages over traditional lighting sources.
One of the key benefits of LED downlights is their energy efficiency. LED technology consumes significantly less energy compared to incandescent and halogen bulbs, making them an environmentally-friendly choice.
Additionally, LED downlights have a longer lifespan, reducing the need for frequent bulb replacements and maintenance.
Furthermore, LED downlights offer exceptional versatility in terms of light direction and color temperature. With adjustable beam angles and a wide range of color options, you can easily customize the lighting in your space to create the desired ambiance. Whether you prefer warm, cozy lighting for a bedroom or bright, cool lighting for a workspace, LED downlights can fulfill your specific lighting needs.
In addition to their energy efficiency and versatility, LED downlights also provide excellent light quality. LED technology produces a high-quality, consistent light output that enhances visual clarity and reduces eye strain. Whether you’re reading a book, working on a project, or simply relaxing in your space, LED downlights ensure optimal lighting conditions for any activity.
Factors to Consider When Choosing LED Downlights
When selecting LED downlights for your space, several factors need to be taken into consideration.
The first factor is the size and layout of the space. Depending on the ceiling height and room size, you may need different wattages and beam angles to achieve the desired lighting effect. It is important to choose downlights that provide sufficient illumination without overpowering the space.
Another crucial factor to consider is the color temperature of the LED downlights. Color temperature refers to the warmth or coolness of the light emitted by the downlights. It is measured in Kelvin (K), with lower Kelvin values indicating warmer light and higher Kelvin values indicating cooler light. The choice of color temperature depends on the mood and functionality of the space. For example, warm white (2700K-3000K) is often preferred for residential areas, creating a cozy and intimate atmosphere, while cool white (4000K-5000K) is commonly used in offices and commercial spaces for a brighter and more energizing environment.
Additionally, it is important to consider the compatibility of the LED downlights with existing dimming systems, if applicable. Not all LED downlights are dimmable, so it is crucial to check the product specifications before making a purchase. Dimmable LED downlights provide the flexibility to adjust the brightness according to your needs, allowing for greater control over the lighting ambiance.
How to Install LED Downlights
Installing LED downlights may seem like a daunting task, but with the right tools and guidance, it can be a straightforward process.
Before starting the installation, ensure that the power to the lighting circuit is turned off to avoid any electrical accidents. It is recommended to consult a qualified electrician for the installation, especially if you are not familiar with electrical work.
To begin the installation, measure and mark the desired locations for the downlights on the ceiling. Use a hole saw or a suitable cutting tool to create openings for the downlights. Make sure to follow the manufacturer’s instructions regarding the size and spacing of the holes.
Once the holes are prepared, connect the LED downlights to the wiring system according to the manufacturer’s instructions. Typically, the downlights will have a positive (+) and negative (-) wire that needs to be connected to the corresponding wires in the electrical circuit. Ensure that the connections are secure and insulated properly to prevent any short circuits or electrical hazards.
After connecting the downlights, gently push them into the prepared holes until they are flush with the ceiling. Most LED downlights come with spring clips or brackets that hold them in place. Ensure that the downlights are properly secured and aligned with the ceiling surface.
Finally, restore the power to the lighting circuit and test the LED downlights to ensure they are functioning correctly. Adjust the beam angles if necessary to achieve the desired lighting effect. If you encounter any issues during the installation or if you are unsure about any step, it is recommended to seek professional assistance.
Proper Maintenance and Care for LED Downlights
LED downlights require minimal maintenance compared to traditional lighting sources. However, a few simple steps can help prolong their lifespan and optimize their performance.
Regular cleaning of the downlights is essential to prevent dust and dirt buildup, which can affect the light output and efficiency. Use a soft, lint-free cloth or a damp sponge to gently wipe the surface of the downlights. Avoid using abrasive materials or harsh chemicals that can damage the LED components or the housing.
In addition to cleaning, it is important to inspect the downlights periodically for any signs of damage or wear. Check the wiring connections, insulation, and housing for any loose or damaged parts. If you notice any issues, it is recommended to contact a qualified technician for repairs or replacements.
Furthermore, it is crucial to follow the manufacturer’s guidelines regarding the operating conditions of the LED downlights. Avoid exposing them to extreme temperatures, moisture, or excessive humidity, as these can affect their performance and lifespan. Additionally, ensure that the downlights are used within their specified voltage range to prevent any damage or electrical hazards.
Comparison of LED Downlights vs. Traditional Lighting Options
LED downlights have numerous advantages over traditional lighting options, such as incandescent and halogen bulbs. One of the key differences is energy efficiency. LED downlights consume significantly less energy compared to traditional bulbs, resulting in reduced electricity bills and lower carbon footprint. LED technology converts most of the energy into light, minimizing wasteful heat generation.
Another significant difference is the lifespan of LED downlights. Traditional bulbs have a limited lifespan, typically ranging from 1,000 to 2,000 hours, whereas LED downlights can last up to 50,000 hours or more. This means fewer replacements and reduced maintenance costs in the long run.
LED downlights also excel in terms of light quality and versatility. LED technology allows for precise control over color temperature and beam angles, providing better lighting experiences. Traditional bulbs often produce uneven light distribution and can emit a yellowish or bluish hue, whereas LED downlights offer consistent, high-quality light output.
Furthermore, LED downlights are more environmentally friendly compared to traditional bulbs. Traditional bulbs contain hazardous materials, such as mercury, which can be harmful to both human health and the environment. LED downlights are mercury-free and do not emit any harmful substances, making them a safer and greener lighting option.
Best Practices for Using LED Downlights in Different Spaces
LED downlights can enhance the aesthetics and functionality of various spaces when used strategically. Here are some best practices for using LED downlights in different environments:
1. **Residential Spaces**: In living rooms and bedrooms, use warm white LED downlights to create a cozy and relaxing atmosphere. Install dimmable downlights for adjustable lighting levels. In kitchens and bathrooms, opt for cool white LED downlights for a bright and vibrant environment. Consider using adjustable downlights to highlight specific areas or objects, such as artwork or countertops.
2. **Commercial Spaces**: In offices and workspaces, use cool white LED downlights to promote productivity and focus. Install adjustable downlights to direct the light towards workstations or collaborative areas. In retail stores, use a combination of fixed and adjustable downlights to create an appealing ambiance and highlight merchandise. Consider using dimmable downlights to create different moods or lighting scenes.
3. **Hospitality Spaces**: In restaurants and cafes, use warm white LED downlights to create a warm and inviting atmosphere. Install dimmable downlights to adjust the lighting ambiance according to different dining experiences or events. In hotels and lobbies, use a combination of fixed and adjustable downlights to highlight architectural features and create a welcoming environment.
4. **Artistic Spaces**: In art galleries and museums, use adjustable or gimbal LED downlights to accentuate artwork and sculptures. Select downlights with a high color rendering index (CRI) to ensure accurate color representation. Consider using track lighting systems to provide flexibility in illuminating different exhibits or changing displays.
Why Choose AiDiWatt Lighting?
At AiDiWatt Lighting, we are dedicated to provide you with the most advanced lighting products to satisfy your customers. We control every aspect of our production process, from design to distribution, so you can rely on our knowledge of everything we produce.
Certified Quality
QC Check for all raw materials. All LED Downlights have passed LM80, CE, RoHS, UKCA test.
Customization
All you need to do is send us your requirements, and we will make your ideas into reality.
Flexible MOQ
Standard models no MOQ required. Easy for you to check samples and test the market.
Competitive Price
We are striving to improve production processes, reduce costs to offer the best possible price.
Fast Delivery
We have more than 80 experienced workers and use automated production lines to ensure faster delivery.
Aftersale Services
All your inquiries and questions will be dealt with promptly and professionally
Frequently Asked Questions
This section contains a few FAQs that our customers ask. If your question is not here, contact us today, and we will answer directly.
Yes, we can provide free samples for your testing. But it would be best if you bore the shipping cost.
There is no MOQ for our regular models. If you want to make a new design, please contact our sales.
If the raw materials are in stock, the delivery time is 10-12 days. Otherwise, the delivery time is 18-20 days.
We generally use DHL, UPS, FEDEX to ship the goods. The days required for transportation vary according to the destination, but the general is 3-7 days.
In general, one led downlight in a box with a air bubble bag. 30pcs boxes in one carton.
Yes. we can print LOGO on the Downlight Housing. Please check the details with our sales.
Yes, all LED Downlights can be produced as phase dimming, 0-10V/1-10V/Dali dimming.
Yes, custom finish colour is available. Please check details with our sales.
Yes, please check with our sales.
More than 50000 hours.
Request a LED Downlight Quote for Your Project
LED downlights are a versatile and energy-efficient lighting solution that can transform any space into a visually stunning masterpiece. With their numerous benefits, including energy efficiency, long lifespan, and superior light quality, LED downlights have become the preferred choice for both residential and commercial applications. By considering factors such as size, layout, and color temperature, and following proper installation and maintenance practices, you can optimize the performance and longevity of LED downlights. So, illuminate your space and create the perfect ambiance with top-quality LED downlights!
