COB LED Strip Light
AiDiWatt Lighting is a professional COB LED Strip Light manufacturer and wholesale supplier in China.
COB LED Strip Light also called “Chip on Board LED Strip”. There are multiple series for your choice: mono color, dual white, RGB, RGBW, Super narrow 3mm 4mm 5mm, Long length 30m/roll, 50m/roll, waterproof IP54/IP65/IP67/IP68.
We offer customized solutions, OEM, ODM service. Tell us what you want now.
What is COB LED Strip Light?
The full name of COB is the Chip On Board: directly package the chip on the circuit board. “Chip on Board” LEDs for flexible cob led strip lights are sometimes referred to as flip-chips. Flip chip LEDs are basically a bare-bones approach to LED construction.
Take a look at an ordinary SMD (Surface Mount Device) LED. It has a Lamp bead holder that package the LED chip and then covers it with a phosphor coating. The ‘flip chip’ that makes up the COB LED strip removes everything from its design, except for the LED chip, yellow phosphor cover layer, and connection pads.
The COB led strip is a high-density led lighting strip made by COB encapsulation, which can reduce the thermal resistance of the high-density strip circuit system, greatly improves the life of the LED, and the light flux density is high, the glare is small, and the light is uniform and there is no dark area.
12mm width COB LED Strip Light
The 12mm width Dotless COB LED Strip Light is new design. Customized by customers’ requirement: they would like to assemble the big width COB LED Strip Light inside the Aluminum Profile directly. The color temperature of white light is 2700K, 3000K, 4000K, and 6000K, and the CRI is greater than 90. The density of chips is 1280 chips per meter. Dotless, Uniform Lighting.
- LED Chip QTY per meter: 1280chips (Sanan brand)
- CRI: >90
- PCB Width Available: 12mm
- Led Color Options: warm white, nature white, cool white
- Input Voltage: DC24V
- Power & Lumen per meter: 15W&1650~1950lm/m
- Light Efficency: 110-130lm/w
- Cuttable Length: 12.5mm
- Waterproof Version: IP20, IP65
- Warranty: 5 years
15mm width COB LED Strip Light
The 15mm width Dotless COB LED Strip Light is new design. Customized by customers’ requirement: they would like to assemble the big width COB LED Strip Light inside the Aluminum Profile directly. The color temperature of white light is 2700K, 3000K, 4000K, and 6000K, and the CRI is greater than 90. The density of chips is 1920 chips per meter. Dotless, Uniform Lighting.
- LED Chip QTY per meter: 1920chips (Sanan brand)
- CRI: >90
- PCB Width Available: 15mm
- Led Color Options: warm white, nature white, cool white
- Input Voltage: DC24V
- Power & Lumen per meter: 25W&2750~3250lm/m
- Light Efficency: 110-130lm/w
- Cuttable Length: 20.67mm
- Waterproof Version: IP20, IP65
- Warranty: 5 years
20mm width COB LED Strip Light
The 20mm width Dotless COB LED Strip Light is new design. Customized by customers’ requirement: they would like to assemble the big width COB LED Strip Light inside the Aluminum Profile directly. The color temperature of white light is 2700K, 3000K, 4000K, and 6000K, and the CRI is greater than 90. The density of chips is 3072 chips per meter. Dotless, Uniform Lighting.
- LED Chip QTY per meter: 3072chips (Sanan brand)
- CRI: >90
- PCB Width Available: 20mm
- Led Color Options: warm white, nature white, cool white
- Input Voltage: DC24V
- Power & Lumen per meter: 30W&3300~3900lm/m
- Light Efficency: 110-130lm/m
- Cuttable Length: 15.5mm
- Waterproof Version: IP20, IP65
- Warranty: 5 years
Mono Dotless COB LED Strip Light
The 8mm/10mm 480chips Dotless COB LED Strip Light is the hotest model. The mono colour includes white, red, green, blue, yellow, orange, tiffany blue, mars green, pink and more. The color temperature of white light is 2700K, 3000K, 4000K, and 6500K, and the CRI is greater than 90. The density of chips is 480 chips per meter. Dotless, Uniform Lighting.
- LED Chip QTY per meter: 480chips (Sanan brand)
- CRI: >90
- PCB Width Available: 8mm, 10mm
- Led Color Options: warm white, nature white, cool white, red, green, blue
- Input Voltage: DC12V, DC24V
- Power & Lumen per meter: 8mm-9W&950lm, 10mm-12W&1200lm
- Cuttable Length: DC12V: 25mm, DC24V: 50mm
- Waterproof Version: IP20, IP54, IP65, IP67, IP68
- Warranty: 5 years
Tunable White Dotless COB LED Strip Light
Tunable White Dotless COB LED Strip Light or CCT adjustable Dotless COB LED Strip Light, up to 640 chips per meter, no light spots. With the tunable white led controller, you can change the color temperature from 2700K to 6500K.
- LED Chip QTY per meter: 512chips, 608chips, 640chips (Sanan brand)
- CRI: >90
- PCB Width Available: 8mm, 10mm
- Led Color Options: 2700K-6500K changeable, other CCT on request
- Input Voltage: DC24V
- Power per meter: 512chips-18W, 608chips-22W, 640chips-22W
- Cuttable Length: 512chips-31.25mm, 608chips-26.31mm, 640chips-50mm
- Waterproof Version: IP20, IP54, IP65, IP67, IP68
- Warranty: 5 years
RGB Dotless COB LED Strip Light
RGB Dotless COB LED Strip Light is high density led chips, up to 840chips per meter—no lighting dots. With the RGB LED controller, you can change the color of the RGB COB LED strip in various ways.
- LED Chip QTY per meter: 480chips, 840chips (Sanan brand)
- CRI: >90
- PCB Width Available: 10mm
- Led Color Options: RGB
- Input Voltage: DC12V, DC24V
- Power per meter: 15W
- Cuttable Length: 525mm, 50mm
- Waterproof Version: IP20, IP65
- Warranty: 5 years
RGBW Dotless COB LED Strip Light
RGBW Dotless COB LED Strip Light is high density led chips, up to 896chips per meter—no lighting dots. With the RGBW LED controller, you can change the color of the RGBW COB LED strip in various ways.
- LED Chip QTY per meter: 896chips (Sanan brand)
- CRI: >90
- PCB Width Available: 12mm
- Led Color Options: RGBW
- Input Voltage: DC24V
- Power per meter: 20W
- Cuttable Length: 31.25mm
- Waterproof Version: IP20, IP65
- Warranty: 5 years
3mm/4mm/5mm width Dotless COB LED Strip Light
The ultra narrow LED strip is an ultra-thin strip light outfitted with extremely bright LED chips and a strong adhesive backing. Ultra Narrow series consists of 3mm LED strip, 4mm led strip, 5mm led strip. It can be used in the installation location or space that is particularly limited, mainly designed for the decorative lighting of the corner, wall edges, and advertising lighting.
- LED Chip QTY per meter: 480chips (Sanan brand)
- CRI: >90
- PCB Width Available: 3mm, 4mm, 5mm
- Led Color Options: warm white, nature white, cool white, red, green, blue
- Input Voltage: DC12V, DC24V
- Power & Lumen per meter: 3mm-5W&400lm, 4mm-6W&480lm, 5mm-7W&560lm
- Cuttable Length: DC12V: 25mm, DC24V: 50mm
- Waterproof Version: IP20, IP65
- Warranty: 5 years
15meters/roll Dotless COB LED Strip Light
The 15meters COB Dotless LED Strip Light is constant current design. Constant current IC chip is added to each group of led circuit loops to automatically adjust the voltage of the LED in the loop to operate at the rated voltage. The brightness of the head and tail of the led strip will remain the same. One side power supply in, keep 15meters the same brightness, is convenient for some lighting project installation.
- LED Chip QTY per meter: 360chips (Sanan brand)
- CRI: >90
- PCB Width Available: 10mm
- Led Color Options: warm white, nature white, cool white
- Input Voltage: DC24V
- Power & Lumen per meter: 10W&800lm
- Cuttable Length: 50mm
- Waterproof Version: IP20, IP54, IP65, IP67, IP68
- Warranty: 5 years
30meters/roll Dotless COB LED Strip Light
The 30meters Dotless COB LED Strip Light is constant current design. Constant current IC chip is added to each group of led circuit loops to automatically adjust the voltage of the LED in the loop to operate at the rated voltage. The brightness of the head and tail of the led strip will remain the same. One side power supply in, keep 30meters the same brightness, is convenient for some lighting project installation.
- LED Chip QTY per meter: 480chips (Sanan brand)
- CRI: >90
- PCB Width Available: 10mm
- Led Color Options: warm white, nature white, cool white
- Input Voltage: DC48V
- Power & Lumen per meter: 10W&800lm
- Cuttable Length: 50mm
- Waterproof Version: IP20, IP54, IP65, IP67, IP68
- Warranty: 5 years
Mini Cut Dotless COB LED Strip Light
Mini cutting COB LED Strip Light can be cut in short length: 5mm, 7.8mm, 8.33mm, 10mm. Usually used together with aluminum profiles, which can solve the problem of dark areas at the end.
- LED Chip QTY per meter: 300chips, 480chips, 512chips, 600chips.
- CRI: >90
- PCB Width Available: 4mm, 8mm, 10mm
- Led Color Options: warm white, nature white, cool white
- Input Voltage: DC5V, DC12V, DC24V
- Power & Lumen per meter: 5W-14W&300lm-1500lm
- Cuttable Length: 5mm, 7.8mm, 8.33mm, 10mm, 10.4mm, 12.5mm, 16.66mm
- Waterproof Version: IP20, IP54, IP65, IP67, IP68
- Warranty: 5 years
Arbitrary Cropping Dotless COB LED Strip Light
Arbitrary Cropping DC12V or 24V Copper COB LED Strip Lights, flexible and easy to install. You can cut anywhere on this COB LED Strip Light without affecting the rest of the strip to work, no matter how long your project needs to run, it will fit well.
- LED Chip QTY per meter: 480chips
- CRI: >90
- PCB Width Available: 5mm, 8mm
- Led Color Options: warm white, nature white, cool white
- Input Voltage: DC12V, DC24V
- Power & Lumen per meter: 6W, 9W-80lm/w
- Cuttable Length: Airbitrary Cropping
- Waterproof Version: IP20, IP54, IP65, IP67, IP68
- Warranty: 5 years
Running Water Dotless COB LED Strip Light
Running Water LED Strip Light also called Chasing LED Strip Light, Flowing LED Strip Light, or Moving LED Strip Light. With WS2811 IC, the lighting can realise water running effect. Can be controlled by remote controller to change the modes.
- LED Chip QTY per meter: 420chips (Sanan brand)
- Pixel: 20IC/meter
- CRI: >90
- PCB Width: 10mm
- Led Color Options: 3000K, 4000K or 6500K
- Input Voltage: DC24V
- Power per meter: 10W
- Cuttable Length: 100mm
- Waterproof Version: IP20, IP67
- Warranty: 5 years
RGB Addressable COB LED Strip Light
Arbitrary Cropping DC12V or 24V Copper COB LED Strip Lights, flexible and easy to install. You can cut anywhere on this COB LED Strip Light without affecting the rest of the strip to work, no matter how long your project needs to run, it will fit well.
- LED Chip QTY per meter: 400chips, 528chips,
- CRI: >90
- PCB Width Available: 8mm, 10mm
- Led Color Options: warm white, nature white, cool white
- Input Voltage: DC12V, DC24V
- Power & Lumen per meter: 8W, 10W, 15W-80lm/w
- Cuttable Length: Airbitrary Cropping
- Waterproof Version: IP20, IP54, IP65, IP67, IP68
- Warranty: 5 years
Waterproof Dotless COB LED Strip Light
IP54 Silicone Glue Covering
IP65 Silicone Sleeve Tube
IP68 Glue Filled in Tube
IP68 Slim Silicone Extrusion
Solderless Connector for Dotless COB LED Strip Light
IP20 Strip to Strip connector
IP20 Strip to Cable connector
IP20 Strip to Strip with Cable
IP65 Strip to Strip connector
IP65 Strip to Cable connector
IP65 Strip to Strip with Cable
Why Choose AiDiWatt Lighting?
At AiDiWatt Lighting, we are dedicated to provide you with the most advanced lighting products to satisfy your customers. We control every aspect of our production process, from design to distribution, so you can rely on our knowledge of everything we produce.
Certified Quality
QC Check for all raw materials. All COB LED Strip Light have passed LM80, CE, RoHS, UKCA test.
Customization
All you need to do is send us your requirements, and we will make your ideas into reality.
Flexible MOQ
Standard models no MOQ required. Easy for you to check samples and test the market.
Competitive Price
We are striving to improve production processes, reduce costs to offer the best possible price.
Fast Delivery
We have more than 80 experienced workers and use automated production lines to ensure faster delivery.
Aftersale Services
All your inquiries and questions will be dealt with promptly and professionally
Frequently Asked Questions
This section contains a few FAQs that our customers ask. If your question is not here, contact us today, and we will answer directly.
Yes, we can provide free samples for your testing. But it would be best if you bore the shipping cost.
There is no MOQ for our regular models. If you want to make a new PCB design, MOQ is 500 meters.
If the raw materials are in stock, the delivery time is 10-12 days. Otherwise, the delivery time is 18-20 days.
We generally use DHL, UPS, FEDEX to ship the goods. The days required for transportation vary according to the destination, but the general is 3-7 days.
In general, 5 meters are packed on a plastic reel and then packed into an anti-static aluminum foil bag. If you order bulk quantity, can make colourful bag/box.
Yes. we can print LOGO on the PCB board. Please check the details with our sales.
Yes, all COB LED Strip Lights are dimmable. Can use dimmer/controller to control the brightness/colour.
Yes, you can cut COB LED Strip Light on the cuttable mark position.
More than 50000 hours.
Yes, it will help the COB LED Strip Light to dissipate heat better and prolong the life of the COB light strip.
